MFC-L8690CDW-RFB Refurbished Colour Laser Multi-Function Printer
$559.00
Professional Colour Laser Multi-Function Printer with Scanner
$559.00
- Up to 31 ppm (Colour & Monochrome)
- Wireless
- Gigabit Ethernet
- Automatic 2-sided (Duplex) Print & Scan
- Replaceable High-Yield Toners
Information
Overview
Automation
Automate scanning jobs and complete tasks with a touch of a button with 64 programmable shortcut buttons
Simultaneous Print & Scan
Remove office bottlenecks with this multi-tasking feature which allows Print & Scan functions to operate simultaneously
Speed
Digitise and print your documents quicker with ultra fast 31ppm print speed and 56ipm Single Pass Duplex Scan / Copy, reducing the time you spend waiting for your task to complete
Professional Quality
Print crisp and professional laser quality documents at 2400dpi delivered by super high-yield toners working with a pre-programmed printer driver
Scalability
Reduce the hassle of changing paper by having various paper types ready to print from multiple paper trays
Workflow Integrations
Utilise software integration options for print and document management requirements, tailored to your business needs. Contact our team to find out more
Specifications
Basic Specs
Functions
Print, Scan, Copy, Fax
Printer Type
Colour Laser
Product Dimensions (Width X Depth X Height)
435 mm × 526 mm × 539 mm
Weight
28.1 kg
Print Speed
31 / 33 ppm (A4/Letter)
Warranty
1 year Return to Base Warranty
Resolution
600 x 600 dpi, 2,400 dpi class (2400 x 600) quality
2-Sided (Duplex) - Printing Paper Type
Plain Paper, Letterhead, Colored Paper, Thin Paper, Recycled Paper, Glossy Paper
2-Sided (Duplex) - Paper Size
A4
Paper handling
Tray #1 - Paper Type
A4, Letter, A5, A5(Long Edge), A6, Executive, Legal, Folio, Mexico Legal
Tray #1 - Maximum Paper Weight
60 to 105 gsm (16 to 28 lb)
Tray #1 - Maximum Paper Capacity
Up to 250 sheets of 80 g/m2 Plain Paper
Tray #1 - Paper Size
A4, Letter, A5, A5 (Long Edge), A6, Executive, Legal, Folio, Mexico Legal
Tray #2 - Maximum Paper Weight
60 to 105 gsm (16 to 28 lb)
Multi-purpose Tray - Maximum Paper Weight
60 to 163 gsm (16 to 43 lb)
Multi-purpose Tray - Paper Size
Width: 76.2 to 215.9 mm (3" to 8.5")
Length: 127 to 355.6 mm (5" to 14")
Envelope: COM-10, DL, C5, Monarch
Multi-purpose Tray - Maximum Paper Capacity
50 sheets Envelope; 10 envelopes up to 10mm thick
Paper Output
150 Sheets Face Down (80g/m2) 1 sheet face-up (straight paper path)
Copy
Colour / Monochrome
Yes
Yes
Multiple Copies
Sorts/Stacks (up to 999 pages)
Resolution
Prints up to 1,200 x 600dpi
Scan
Colour / Monochrome
Yes / Yes
Resolution - Interpolated
Up to 19,200 × 19,200 dpi
Resolution - Scanner Glass
Up to 1,200 × 2,400 dpi (optical)
Resolution - Automatic Document Feeder (ADF)
Up to 1,200 x 600 dpi (optical)
Document Scanning Width / Length - Scanner Glass
Width: Up to 215.9 mm
Length: Up to 300 mm
Document Scanning Width / Length - Automatic Document Feeder (ADF)
Width: 105 to 215.9 mm
Length: 147.3 to 355.6 mm
1-Sided (Simplex) - Scan Speed
Up to 28 (Mono) / Up to 28 (Colour) ipm (A4)
Up to 29 (Mono) / Up to 29 (Colour) ipm (Letter)
2-Sided (Duplex) - Scan Speed
Up to 56 (Mono) / Up to 56 (Colour) ipm (A4)
Up to 58 (Mono) / Up to 58 (Colour) ipm (Letter)
Fax
Modem Speed
33,600 bps
Memory Transmission
Up to 500 pages (ITU-T Test Chart, Standard Resolution, JBIG)
Fax Forwarding
Yes
Out of Paper Reception
Up to 500 pages (ITU-T Test Chart, Standard Resolution, JBIG)
Connectivity
WiFi Direct
Yes
Connectivity
Hi-SpeedUSB2.0, Ethernet 10Base-T/100Base-TX/1000Base-T, Wireless LAN IEEE 802.11b/g/n (Infrastructure/Ad-hoc Mode), IEEE 802.11g/n (Wi-Fi Direct)
Display & Memory
Display Type
3.7" TFT Colour LCD
Memory Capacity
1 GB
Operation
Power Source
AC 220 to 240V 50/60Hz
Power Consumption - Printing
Approx. 580W
Power Consumption - Ready
Approx. 70 W
Power Consumption - Sleep
Approx. 10.0 W
Power Consumption - Power Off
Approx. 0.03 W
Noise Level
49 dB (A) (Approx.)
Supported Operating Systems
Supported OS
Server 2008 (Network only), Server 2008 R2 (Network only), 7, 8, 8.1, Server 2012 (Network only), Server 2012 R2 (Network only), 10, Server 2016 (Network only)
macOS v10.10.5, v10.11.x, v10.12 (Download only)
Software and Apps
Mobile Apps
21/12/2023
iPrint&Scan, Support Center, Print Service Plugin
