Colour LED Multi-Function Centre
- Up to 22/22ppm
- Up to 600 x 600 dpi, 2400 x 600 dpi
- Automatic Document Feeder
- Replaceable high-yield toners available
The MFC-9140CDN is a high speed Multi-Function Centre which combines rich features in a sleek, compact design. With print speeds of up to 22ppm, network connectivity and 2-Sided printing the MFC-9140CDN does it all with ease. Also offering high-yield toner cartridges to help reduce your total print costs, this new colour Multi-Function Centre is perfect for any busy office environment.
Information
Overview
Specifications
Basic Specs
Functions
Print, Scan, Copy, Fax
Printer Type
Laser Printer
Product Dimensions (Width X Depth X Height)
410 mm × 483 mm × 410 mm
Weight
23.6 kg
Print Speed
Up to 22 pages/minute (A4 size)
Paper Type
Paper Tray - Plain Paper, Thin Paper, Recycled Paper
Manual Feed Slot - Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond Paper, Label, Envelope, Env.Thin, Env.Thick, Glossy Paper
Paper Size
Paper Tray - A4, Letter, B5 (JIS), A5, A5 (Long Edge), A6, Executive, Legal, Folio
Manual Feed Slot - Width: 76.2 to 215.9 mm | Length: 116.0 to 355.6 mm
Maximum Paper Capacity
Paper Tray - Up to 250 sheets of 80 gsm Plain Paper
Manual Feed Slot - One sheet at a time
Warranty
1 year Return to Base Warranty
Resolution
600 dpi x 600 dpi, 2400 dpi (600 dpi x 2400 dpi) quality
2-Sided (Duplex) - Printing Paper Type
Plain Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) - Paper Size
A4
Paper handling
Tray #1 - Paper Type
Plain Paper, Thin Paper, Recycled Paper
Tray #1 - Maximum Paper Capacity
Up to 250 sheets of 80 gsm Plain Paper
Manual Feed Slot - Paper Type
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond Paper, Label, Envelope, Env.Thin, Env.Thick, Glossy Paper
Paper Output
Up to 100 sheets of 80 gsm Plain paper (face-down delivery to the face-down output paper tray)
Copy
Multiple Copies
Stacks or Sorts up to 99 pages
Enlarge/ Reduce
25% to 400% (in increments of 1%)
Resolution
Up to 600 x 600 dpi
Scan
Resolution - Interpolated
Up to 19200 x 19200 dpi
Resolution - Scanner Glass
Up to 1200 x 2400 dpi (optical)
Resolution - Automatic Document Feeder (ADF)
Up to 1200 x 600 dpi (optical)
Fax
Compatibility
ITU-T Super Group 3
Modem Speed
33,600 bps (with Automatic Fallback)
Memory Transmission
Up to 500 pages
Out of Paper Reception
Up to 500 pages
Connectivity
Connectivity
Hi-SpeedUSB2.0, Ethernet 10Base-T/100Base-TX
Display & Memory
Display Type
3.7" Touch Screen LCD Panel
Memory Capacity
192 MB
Operation
Power Source
220 - 240 V AC 50/60 Hz
Power Consumption - Ready
Approx. 70 W at 25 °C
Power Consumption - Sleep
Approx. 8.5 W
Power Consumption - Power Off
Approx. 0.05 W
Noise Level
Lpam = 53.0 dB (A)
Supported Operating Systems
Supported OS
Windows 8 , Windows XP Home Edition, XP Professional Edition, XP Professional x64 Edition, Windows Vista, Windows 7, Windows Server 2003 , Windows Server 2003 x64 Edition, Windows Server 2008, Windows Server 2008 R2 (Network Only), Windows Server 2012
Mac OS® X 10.6.8, 10.7.x and 10.8.x
Software and Apps
Mobile Apps
21/12/2023
iPrint&Scan, Support Center, Print Service Plugin
