ADS-2800W Desktop Document Scanner

Compare

office document scanner brother ads-2800w

wireless desktop document scanner brother ads-2800w

Discontinued Product

Discontinued Product

Brother ADS-2800W

Wired & Wireless Network Document Scanner

50 sheet mixed batch document capacity from long paper to embossed plastic cards
Fast double sided-scans
Achieve optimum performance with TWAIN, WIA, ICA, SANE drivers
Free premium software bundle, including ABBYY FineReader Sprint and Nuance PaperPort

Perfect for your business or home office, Brother’s ADS-2800W Wireless Network Scanner is the professional and user-friendly scanner your team has been waiting for. Featuring rapid 2-sided (duplex) colour scans, scan speeds of up to 40ppm, high-speed wired and wireless connectivity, and a lockable and intuitive 9.3cm colour LCD touchscreen, this scanner is ideal for quickly scanning to cloud services and emails. And, with premium software for both PCs and Macs, as well as advanced image processing functions that prepare and clean scanned images, your digital documents will never look better.

Information

Basic Specs

Scanning Speed

40 ppm (1.5 seconds (A4/LTR))

Document Size - Multiple Sheets - Width

51 mm to 215.9 mm

Document Size - Multiple Sheets - Length

51 mm to 355.6 mm

Document Size - Single Sheet - Width

51 mm to 215.9 mm

Document Size - Single Sheet - Length

51 to 5,000 mm

Colour / Monochrome

Yes / Yes

2-Sided (Duplex) Scan

Yes

Colour Depth - Input

30-bit colour processing

Colour Depth - Output

24-bit colour processing

Resolution - Optical

Max. 600 dpi × 600 dpi

Resolution - Interpolated

Max. 1,200 dpi × 1,200 dpi

Document Scanning Width / Length

Max. 215 mm

Product Dimensions (Width X Depth X Height)

306 mm × 250 mm × 258 mm

Weight

4.6 kg

ADF (Automatic Document Feeder)

Up to 50 pages (Paper: 80 g/m²)

Memory Capacity

512 MB

Warranty

1 year Return to Base Warranty

What's in The Box

Scanner, Quick Setup Guide, User's Guide, Network Guide, CD-ROM's, ADF Document Output Support, Power Cord, USB cable

Network

Wireless Network Security

WEP 64/128-bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), Enterprise WPA/WPA-PSK (AES), EAP, EAP RAST, PEAP, EAP TTLS, EAP TLS

Setup Support Utility

WPS
WLAN Assistant

Display Type

Touchscreen LCD

3.7 inches (93.4 mm), TFT colour LCD screen

Operation

Power Source

AC: 220 - 240 V, 50/60 Hz

Power Consumption - Scanning

Approx. 27W

Power Consumption - Ready

Approx. 3.7W

Power Consumption - Power Saving / Deep Sleep

Approx. 1.9W

Power Consumption - Power OFF

Approx. 0.12W

Temperature Operating

5°C to 35°C

Humidity - Operating

20% to 80%

Humidity - Storage

10% to 90%

Compliance

TWAIN Compliant - Windows®

Windows® XP Home (SP3) / Windows® XP Professional (SP3, x32 only) / Windows Vista® / Windows Server® 2003 (only 32 bit) / Windows Server® 2008 / Windows Server® 2008 R2 / Windows Server® 2012 / Windows Server® 2012 R2 / Windows® 7 / Windows® 8 / Windows® 8.1

TWAIN Compliant - Macintosh

OS X 10.8.5, 10.9.x, 10.10.x

WIA Compliant - Windows®

Windows® XP (SP3) / Windows Vista® / Windows® 7 / Windows® 8 / Windows® 8.1

ICA Compliant - Macintosh

OS X 10.8.5, 10.9.x, 10.10.x

ISIS™ Compliant - Windows®

Windows Vista® / Windows® 7 / Windows® 8 / Windows® 8.1

Software and Apps

Included Software

12/21/2023

Windows: iPrint&Scan¹, PaperPort 14 SE¹, ABBYY FineReader Sprint¹, ABBYY PDF Transformer Plus¹, Control Centre 4¹, BRAdmin Professional 4¹, Brother Meter Read Tool¹, Mass Deployment Tool¹, ISIS Driver¹ Mac: ABBYY FineReader Sprint¹, iPrint&Scan Push Scan Tool¹

Mobile Apps
